ONSHORE PIPELINE
ONSHORE PIPELINE – TRANSMISSION SYSTEMS
Outside Diameter：Φ219mm – 1420mm (8.6″ – 56″ )
Wall Thickness：5.0 – 25mm (0.2″ – 1″)
Quality Standards：API 5L、ISO 3183、ASME B36.10M、DNV-ST-F101、AS 2885.2:2007、CSA Z662:2007
Length：6 – 18m ( 20”- 60”)
Coating : FBE, 3LPE, 3LPP, Concrete Weight Coating (CWC), or as per project requirements
description
ONSHORE PIPELINE is the core infrastructure for the long-distance transportation of oil, natural gas, water resources, and industrial media on land. They are made of high-strength welded steel pipes (such as LSAW/SSAW/ERW). Through strict material selection, welding processes, and multi-layer anti-corrosion treatments, they ensure safe operation under complex geological and climatic conditions. Their typical design life is 30-50 years, suitable for high-pressure, high-flow transportation scenarios, with advantages such as high efficiency, low loss, and easy maintenance.
Translated with DeepL.com (free version)
Product Name: Onshore Transmission Pipeline, Cross-Country Pipeline
Specifications:
Outer Diameter: 219mm–1420mm
Wall Thickness: 5.0 – 25mm
Length: 6-12m / 18m (custom lengths available)
Standard and Steel Grade:
API SPEC 5L: PSL1/PSL2 Gr.B, X42, X52, X60, X65, X70, X80
ISO 3183: L245, L290, L360, L415, L450, L485
GB/T 9711: L245N, L360M, L415Q
ASME B31.4/B31.8
Ends: Bevelled ends / Plain ends with protector
Surface Treatment
Corrosion protection layer: FBE (fused epoxy powder), 3LPE (three-layer polyethylene), 3LPP (three-layer polypropylene)
Special protection: UV reinforcement layer for desert areas, insulation layer for permafrost areas, cathodic protection for high salt and alkali areas
Ballast: Concrete ballast layer (CWC, used for crossing marshes/waterways)
Specification
ONSHORE PIPELINE Specification Range Reference Table
| Parameters | Typical range | Extreme range | Standard basis | Engineering constraints |
| Outside diameter | ⌀406mm~⌀1219mm | ⌀203mm~⌀1422mm | API 5L | >1219mm requires specialized transport |
| Wall thickness | 8.0mm~20mm | 6.0mm~40mm | ASME B31.4 | Thickness >30mm requires PWHT |
| Length | 12m (double random) | 10m~18m | ISO 318310m~18m | >14m requires special handling |
ONSHORE PIPELINE Standards and Applications Comparison Table
| Classification | Standard | Positioning | Applicability |
| Material Standard | API 5L PSL2 | Global baseline for line pipe | Mandatory for all oil/gas transmission projects |
| Design Standard | ASME B31.4/B31.8 | US pressure pipeline code | Oil (B31.4) / Gas (B31.8) systems |
| Corrosion Control | ISO 21809-1 | External coating qualification | High-risk corrosion environments |
| Safety Standard | DNVGL-ST-F101 | Integrated pipeline design | Arctic, seismic, and HVDC zones |
application
Multi-layer corrosion protection: Effectively resist soil corrosion and weathering erosion, and significantly extend the service life of pipelines.
High-strength steels: Ensures structural integrity, adapts to geological displacements, and operates reliably even at low temperatures.
Unrivaled terrain adaptability:
Built for harsh environments: Specially designed for extreme terrain such as deserts, tundras and swamps.
Seismic Structure: The robust structural design ensures safe operation during geological disasters such as earthquakes.
Cost-effective and practical:
Significant cost savings: Significant cost savings over long distances compared to road or rail transport.
Rapid deployment: The modular design facilitates rapid construction and installation, significantly shortening the overall project cycle.
Intelligent management:
Real-time health monitoring: Compatible with smart inspection equipment for continuous assessment of pipeline integrity.
Precise flow control: The remote control system adjusts the conveying flow rate precisely as needed.
advantages
Exceptional Structural Integrity
- Engineered to transfer massive structural loads deep into stable soil strata
- Uniform wall thickness distribution prevents stress concentration
- Rigorous welding inspection ensures seam reliability under dynamic loads
Advanced Corrosion Protection
- Multi-layer defense systems for saltwater/chemical exposure environments
- Hot-dip galvanizing creates metallurgical bond for decades of protection
- Customizable epoxy coatings adapt to soil acidity and groundwater conditions
Superior Geotechnical Adaptability
- Optimized for driving through dense gravel, sand, and clay layers
- Special end configurations prevent soil plugging during installation
- Consistent surface profile maximizes skin friction in variable strata
Efficient Field Deployment
- Bevel-cut ends enable rapid on-site welding for depth extension
- Driving shoe options reduce tip resistance in rocky substrates
- Minimal site preparation required compared to cast-in-place piles
Precision Manufacturing Excellence
- Computer-controlled forming guarantees straightness and roundness
- Automated weld tracking eliminates human error in seam quality
- Ultrasonic testing verifies integrity along full pipe length
Long-Term Economic Value
- 50+ year service life reduces replacement costs in critical infrastructure
- Lower maintenance requirements versus concrete alternatives
- Scrap value retention for sustainable lifecycle management
Logistics Flexibility
- Custom-cut lengths minimize waste on constrained job sites
- Pre-coated options eliminate post-installation surface treatment
Bundle packaging optimizes transport space utilization
packing
Precision End Protection
Both beveled ends and flat ends are fitted with collision-resistant sleeves for sealing and moisture protection.
Special removable frame protection for welded beveled ends.
Comprehensive Pipe Body Protection
Corrosion-resistant coating covered with elastic protective film (compatible with 3LPE/FBE coatings, etc.).
Custom foam padding + reinforced packaging for special components such as bent pipes.
Intelligent Transportation Solutions
Road Transportation:
Short pipes are securely fixed in containers.
Specialized vehicles for long pipes equipped with anti-slip brackets
Marine transportation solutions:
Anti-slip treatment in bulk cargo ships
Nitrogen-filled containers for moisture protection
Scientific storage management
Pipes are evenly elevated at the bottom, with layers separated to prevent friction
Stack height is controlled by diameter (large-diameter pipes stored on lower layers)
Outdoor storage is covered with protective tarpaulins (sand/salt fog protection)
Intelligent tracking system
Electronic tag scanning for traceability
Color rings on the pipe body indicate steel grade and flow direction
Lifting points clearly marked
