SSAW STEEL PIPE
SSAW STEEL PIPE- JCOE PROCESS
Outside Diameter：Φ219mm – 2540mm (8″ – 100″)
Wall Thickness：5.0 – 25.4mm (0.2″ – 1″)
Quality Standards：API, ISO, EN, ASTM, DIN, JIS, GB, CSA, GOST
Length：6m – 18m (20″ – 60″)
Coating：Bare, FBE, 3LPE, 3LPP, or as per client requirements
description
SSAW steel pipe is carefully crafted from high quality hot rolled steel coils using advanced spiral forming and submerged arc welding technology. Its unique spiral weld design provides excellent pressure-bearing capacity and overall structural strength, making it particularly suitable for large-diameter, high-pressure transmission applications. Our submerged arc welded steel pipes are available in a wide range of specifications, with high production efficiency and cost-effectiveness. They are widely used in oil and gas transmission pipelines, water conservancy projects, municipal pipeline networks, building structural piles, bridge construction and various fluid transportation projects. Strict adherence to international standards (e.g. API 5L, ASTM A252, EN 10219) ensures stable and reliable product performance and meets the stringent requirements of customers worldwide.
Product Name: SSAW Steel Pipe，Spiral Welded Pipe, HSAW Pipe
Specifications:
Outer Diameter: 219mm – 2540mm
Wall Thickness: 5.0 – 25.4mm
Length: 6m / 12m / 18m (customizable)
Standard and Steel Grade:
API SPEC 5L: Gr.B, X42, X52, X60, X65, X70 (PSL1/PSL2)
ASTM A139: Grade A, B, C
EN 10217/EN 10219: S235JR, S355J0, S355J2
GB/T 9711: L245, L290, L360, L415
AS/NZS 1074: DN250-DN1000
JIS G 3444: STK400, STK500
DIN 2463: St37.0, St52.0
Ends: Plain ends, Bevelled ends (30°±5°), Flange welded
Surface Treatment: Bare, Black painting, FBE, 3LPE, 3LPP, Galvanized
Specification
| Out Diameter | Wall Thickness (mm) | |||||||||||||||||||||
| mm | inch | 6.0 | 7.0 | 8.0 | 9.0 | 10.0 | 11.0 | 12.0 | 13.0 | 14.0 | 15.0 | 16.0 | 17.0 | 18.0 | 19.0 | 20.0 | 21.0 | 22.0 | 23.0 | 24.0 | 25.00 | |
| 219.1 | 8.0 | 31.53 | 36.61 | 41.65 | 46.63 | |||||||||||||||||
| 273.0 | 10.0 | 39.51 | 45.92 | 52.28 | 58.59 | 64.86 | ||||||||||||||||
| 323.9 | 10.0 | 47.04 | 54.70 | 62.32 | 69.89 | 77.41 | 84.88 | 92.30 | ||||||||||||||
| 325.0 | 47.20 | 54.89 | 62.54 | 70.13 | 77.68 | 85.18 | 92.62 | |||||||||||||||
| 355.6 | 14.0 | 51.73 | 60.18 | 68.57 | 76.92 | 85.22 | 93.48 | 101.68 | ||||||||||||||
| 377.0 | 54.89 | 63.87 | 72.80 | 81.67 | 90.50 | 99.28 | 108.01 | 116.69 | ||||||||||||||
| 406.4 | 16.0 | 59.24 | 68.94 | 78.60 | 88.20 | 97.75 | 107.26 | 116.71 | 126.12 | |||||||||||||
| 426.0 | 62.14 | 72.33 | 82.46 | 92.55 | 102.59 | 112.57 | 122.51 | 132.40 | ||||||||||||||
| 457.0 | 18.0 | 66.73 | 77.68 | 88.58 | 99.43 | 110.23 | 120.98 | 131.68 | 142.34 | |||||||||||||
| 478.0 | 69.84 | 81.30 | 92.72 | 104.09 | 115.41 | 126.68 | 137.90 | 149.07 | ||||||||||||||
| 508.0 | 20.0 | 74.28 | 86.48 | 98.64 | 110.75 | 122.81 | 134.82 | 146.78 | 158.69 | 170.55 | ||||||||||||
| 529.0 | 77.38 | 90.11 | 102.78 | 115.41 | 127.99 | 140.51 | 152.99 | 165.42 | 177.80 | |||||||||||||
| 610.0 | 24.0 | 89.37 | 104.09 | 118.76 | 133.39 | 147.96 | 162.48 | 176.96 | 191.39 | 205.76 | ||||||||||||
| 630.0 | 92.33 | 107.54 | 122.71 | 137.82 | 152.89 | 167.91 | 182.88 | 197.80 | 212.67 | 227.49 | ||||||||||||
| 660.0 | 26.0 | 96.77 | 112.72 | 128.63 | 144.48 | 160.29 | 176.05 | 191.76 | 207.42 | 223.03 | 238.59 | |||||||||||
| 711.0 | 28.0 | 104.31 | 121.52 | 138.69 | 155.80 | 172.87 | 189.88 | 206.85 | 223.76 | 240.63 | 257.45 | 274.22 | ||||||||||
| 720.0 | 105.64 | 123.08 | 140.46 | 157.80 | 175.09 | 192.32 | 209.51 | 226.65 | 243.74 | 260.78 | 277.77 | |||||||||||
| 813.0 | 32.0 | 139.13 | 158.81 | 178.44 | 198.02 | 217.55 | 237.03 | 256.46 | 275.85 | 295.18 | 314.46 | 333.70 | 352.88 | |||||||||
| 820.0 | 140.34 | 160.19 | 179.99 | 199.75 | 219.45 | 239.10 | 258.71 | 278.26 | 297.77 | 317.23 | 336.63 | 355.99 | 375.30 | |||||||||
| 920.0 | 179.92 | 202.19 | 224.41 | 246.58 | 268.70 | 290.77 | 312.79 | 334.76 | 356.68 | 378.56 | 400.38 | 422.15 | ||||||||||
| 1020.0 | 40.0 | 199.65 | 224.38 | 249.07 | 273.70 | 298.29 | 322.82 | 347.31 | 371.75 | 396.14 | 420.48 | 444.77 | 469.01 | |||||||||
| 1220.0 | 48.0 | 239.10 | 268.77 | 298.39 | 327.95 | 357.47 | 386.94 | 416.36 | 445.73 | 475.05 | 504.32 | 533.54 | 562.72 | |||||||||
| 1420.0 | 56.0 | 313.16 | 347.71 | 382.21 | 416.66 | 451.06 | 485.41 | 519.71 | 553.96 | 588.17 | 622.32 | 656.42 | ||||||||||
| 1620.0 | 397.03 | 436.46 | 475.84 | 515.17 | 554.46 | 593.69 | 632.87 | 672.01 | 711.10 | 750.13 | ||||||||||||
| 1820.0 | 490.71 | 535.02 | 579.29 | 623.50 | 667.67 | 711.79 | 755.85 | 799.87 | 843.84 | |||||||||||||
| 2020.0 | 594.21 | 643.40 | 692.55 | 741.65 | 790.70 | 839.70 | 888.65 | 937.55 | ||||||||||||||
| 2220.0 | 707.52 | 761.60 | 815.63 | 869.61 | 923.54 | 977.42 | 1031.26 | |||||||||||||||
| 2500.0 | 797.28 | 858.27 | 919.20 | 980.09 | 1040.92 | 1101.71 | 1162.45 | 1223.14 | 1283.77 | 1344.36 | 1404.90 | 1465.40 | 1525.84 | |||||||||
| 2540.0 | 872.08 | 934.00 | 995.87 | 1057.69 | 1119.47 | 1181.19 | 1242.86 | 1304.49 | 1366.07 | 1427.59 | 1489.07 | 1550.50 | ||||||||||
| 3500.0 | 1289.10 | 1374.65 | 1460.14 | 1545.59 | 1630.99 | 1716.34 | 1801.63 | 1886.88 | 1972.08 | 2057.24 | 2142.34 | |||||||||||
production process
application
Oil and gas: water injection lines, gathering lines, low-pressure transmission lines.
Water Infrastructure: Drainage pipelines, river crossing pipelines, municipal sewerage systems.
Structures: Piling pipes, bridge supports, temporary building frames.
Industry : HVAC piping, coal slurry transportation, mine ventilation.
Special: Wind turbine tower columns, agricultural irrigation.
advantages
Diameter Flexibility: Extensive range (8″–100″) enables custom solutions for large-scale projects.
Economic Efficiency: Lower production cost vs. LSAW/seamless pipes for comparable diameters.
Continuous Weld Strength: Spiral weld distributes stress evenly, enhancing structural integrity.
Rapid Production: Continuous coil feeding allows high-volume output.
Adaptability: Handles non-uniform loads effectively (e.g., seismic zones).
Material Utilization: Minimal waste during spiral forming.
packing
SSAW pipes are bundled with steel straps and protected at ends using plastic caps.
For sea transport:
Container Shipping: For pipes ≤6m length.
Bulk Vessels: Cost-effective for large volumes; pipes stacked with timber dunnage.
Specialized Pipe Carriers: Optimal for ultra-long pipes (18m+), preventing deformation.
Key precautions: Anti-corrosion wrapping, spiral alignment during stacking, and reinforced end protection.
